public class NumberProgressView extends View {

  /**
   * 進度條畫筆的寬度
   */
  private int paintProgressWidth = 3;

  /**
   * 文字百分比的字體大?。╯p）
   */
  private int paintTextSize = 20;

  /**
   * 左側已完成進度條的顏色
   */
  private int paintLeftColor = 0xff67aae4;

  /**
   * 右側未完成進度條的顏色
   */
  private int paintRightColor = 0xffaaaaaa;

  /**
   * 百分比文字的顏色
   */
  private int paintTextColor = 0xffff0077;

  /**
   * Contxt
   */
  private Context context;

  /**
   * 主線程傳過來進程 0 - 100
   */
  private int progress;

  /**
   * 得到自定義視圖的寬度
   */
  private int viewWidth;

  /**
   * 得到自定義視圖的Y軸中心點
   */
  private int viewCenterY;

  /**
   * 畫左邊已完成進度條的畫筆
   */
  private Paint paintleft = new Paint();

  /**
   * 畫右邊未完成進度條的畫筆
   */
  private Paint paintRight = new Paint();

  /**
   * 畫中間的百分比文字的畫筆
   */
  private Paint paintText = new Paint();

  /**
   * 要畫的文字的寬度
   */
  private int textWidth;

  /**
   * 畫文字時底部的坐標
   */
  private float textBottomY;

  /**
   * 包裹文字的矩形
   */
  private Rect rect = new Rect();

  /**
   * 文字總共移動的長度（即從0%到100%文字左側移動的長度）
   */
  private int totalMovedLength;

  public NumberProgressView(Context context, AttributeSet attrs) {
    super(context, attrs);
    this.context = context;
    // 構造器中初始化數據
    initData();
  }

  /**
   * 初始化數據
   */
  private void initData() {

    //設置進度條畫筆的寬度
    int paintProgressWidthPx = Utils.dip2px(context, paintProgressWidth);

    //設置百分比文字的尺寸
    int paintTextSizePx = Utils.sp2px(context, paintTextSize);

    // 已完成進度條畫筆的屬性
    paintleft.setColor(paintLeftColor);
    paintleft.setStrokeWidth(paintProgressWidthPx);
    paintleft.setAntiAlias(true);
    paintleft.setStyle(Style.FILL);

    // 未完成進度條畫筆的屬性
    paintRight.setColor(paintRightColor);
    paintRight.setStrokeWidth(paintProgressWidthPx);
    paintRight.setAntiAlias(true);
    paintRight.setStyle(Style.FILL);

    // 百分比文字畫筆的屬性
    paintText.setColor(paintTextColor);
    paintText.setTextSize(paintTextSizePx);
    paintText.setAntiAlias(true);
    paintText.setTypeface(Typeface.DEFAULT_BOLD);

  }

  @Override
  protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
    super.onMeasure(widthMeasureSpec, heightMeasureSpec);
    getWidthAndHeight();
  }

  /**
   * 得到視圖等的高度寬度尺寸數據
   */
  private void getWidthAndHeight() {

    //得到包圍文字的矩形的寬高
    paintText.getTextBounds("000%", 0, "000%".length(), rect);
    textWidth = rect.width();
    textBottomY = viewCenterY + rect.height() / 2;

    //得到自定義視圖的高度
    int viewHeight = getMeasuredHeight();
    viewWidth = getMeasuredWidth();
    viewCenterY = viewHeight / 2;
    totalMovedLength = viewWidth - textWidth;

  }

  @Override
  protected void onDraw(Canvas canvas) {
    super.onDraw(canvas);

    //得到float型進度
    float progressFloat = progress / 100.0f;

    //當前文字移動的長度
    float currentMovedLentgh = totalMovedLength * progressFloat;

    //畫左側已經完成的進度條，長度為從Veiw左端到文字的左側
    canvas.drawLine(0, viewCenterY, currentMovedLentgh, viewCenterY, paintleft);

    //畫右側未完成的進度條，這個進度條的長度不是嚴格按照百分比來縮放的，因?yàn)槲淖值拈L(zhǎng)度會變化，所以它的長度縮放比例也會變化
    if (progress < 10) {
      canvas.drawLine(currentMovedLentgh + textWidth * 0.5f, viewCenterY, viewWidth, viewCenterY, paintRight);
    } else if (progress < 100) {
      canvas.drawLine(currentMovedLentgh + textWidth * 0.75f, viewCenterY, viewWidth, viewCenterY, paintRight);
    } else {
      canvas.drawLine(currentMovedLentgh + textWidth, viewCenterY, viewWidth, viewCenterY, paintRight);
    }

    //畫文字(注意：文字要最后畫，因?yàn)槲淖趾瓦M(jìn)度條可能會有重合部分，所以要最后畫文字，用文字蓋住重合的部分)
    canvas.drawText(progress + "%", currentMovedLentgh, textBottomY, paintText);
  }

  /**
   * @param progress 外部傳進來的當前進度
   */
  public void setProgress(int progress) {
    this.progress = progress;
    invalidate();
  }
}

public class NumberProgressBarActivity extends Activity {

  protected static final int WHAT_INCREASE = 1;
  private NumberProgressView np_numberProgressBar;
  private int progress;

  private Handler handler = new Handler() {
    public void handleMessage(android.os.Message msg) {
      progress++;
      np_numberProgressBar.setProgress(progress);
      handler.sendEmptyMessageDelayed(WHAT_INCREASE, getRadomNumber(50, 200));
      if (progress >= 100) {
        handler.removeMessages(WHAT_INCREASE);
      }
    }
  };

  @Override
  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_number_progress_bar);
    np_numberProgressBar = (NumberProgressView) findViewById(R.id.np_numberProgressBar);
    Button btn_numberProgressBar = (Button) findViewById(R.id.btn_numberProgressBar);
    btn_numberProgressBar.setOnClickListener(new OnClickListener() {
      @Override
      public void onClick(View v) {
        increase();
      }
    });
  }

  private void increase() {
    progress = 0;
    np_numberProgressBar.setProgress(0);
    handler.removeMessages(WHAT_INCREASE);
    handler.sendEmptyMessage(WHAT_INCREASE);
  }

  /**
   * 得到兩個整數之間的一個隨機數
   *
   * @param start 較小的數
   * @param end  較大的數
   * @return
   */
  public int getRadomNumber(int start, int end) {
    return (int) (start + Math.random() * (end - start));
  }
}

/**
   * 將dip或dp值轉換為px值，保證尺寸大小不變
   */
  public static int dip2px(Context context, float dipValue) {
    final float scale = context.getResources().getDisplayMetrics().density;
    return (int) (dipValue * scale + 0.5f);
  }

  /**
   * 將sp值轉換為px值，保證文字大小不變
   */
  public static int sp2px(Context context, float spValue) {
    final float fontScale = context.getResources().getDisplayMetrics().scaledDensity;
    return (int) (spValue * fontScale + 0.5f);
  }

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
       android:layout_width="match_parent"
       android:layout_height="match_parent"
       android:orientation="vertical">

  <com.example.viewdemo.view.NumberProgressView
    android:id="@+id/np_numberProgressBar"
    android:layout_width="wrap_content"
    android:layout_height="100dp"
    android:layout_margin="20dp"
    android:background="#33890075"
    />

  <Button
    android:id="@+id/btn_numberProgressBar"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:text="開始"/>

</LinearLayout>
