dockerfile構建haproxy的詳細過程(構建HAProxy的鏡像)

更新時間：2025年03月13日 09:44:29 作者：wssswsss

Dockerfile是一個用于構建Docker鏡像的文本文件,包含了構建鏡像所需的所有指令和說明,通過定義一系列命令和參數,本文詳細介紹了如何使用Dockerfile一步步構建HAProxy的鏡像,并指導如何創建和運行容器,實現負載均衡服務,感興趣的朋友一起看看吧

什么是 Dockerfile？

Dockerfile 是一個文本文件，包含了構建 Docker 鏡像的所有指令。

Dockerfile 是一個用來構建鏡像的文本文件，文本內容包含了一條條構建鏡像所需的指令和說明。

通過定義一系列命令和參數，Dockerfile 指導 Docker 構建一個自定義的鏡像。

1. 結構目錄

[root@localhost ~]# tree haproxy/
haproxy/
├── dockerfile
└── files
    ├── haproxy-2.5.0.tar.gz
    ├── haproxy.cfg
    ├── install.sh
    └── start.sh
1 directory, 5 files
[root@localhost ~]#

[root@localhost ~]# cd haproxy/
[root@localhost haproxy]# ls
dockerfile  files
[root@localhost haproxy]# cat dockerfile
FROM centos
LABEL MAINTAINER='pengyudong 1@2.com@qq.com'
ENV version 2.5.0
ADD files/haproxy-${version}.tar.gz /usr/src
ADD files/haproxy.cfg /etc/haproxy/
ADD files/install.sh /tmp/
ADD files/start.sh /usr/local/
RUN ["/bin/bash","-c","/tmp/install.sh"]
EXPOSE 80 8189
WORKDIR /usr/local/haproxy
CMD ["/usr/local/start.sh"]
[root@localhost haproxy]#
[root@localhost haproxy]# cd files/
[root@localhost files]# ls
haproxy-2.5.0.tar.gz  haproxy.cfg  install.sh  start.sh
[root@localhost files]# vim start.sh
[root@localhost files]# cat start.sh
#!/bin/sh
/usr/local/haproxy/sbin/haproxy -f /etc/haproxy/haproxy.cfg
/bin/bash
[root@localhost files]# cat install.sh
#!/bin/bash
rm -rf /etc/yum.repos.d/*
curl -o /etc/yum.repos.d/CentOS-Base.repo https://mirrors.aliyun.com/repo/Centos-$(awk -F'"' 'NR==2{print $2}' /etc/os-release).repo
yum -y install make gcc gcc-c++ pcre-devel bzip2-devel openssl-devel systemd-devel
useradd -r -M -s /sbin/nologin haproxy
cd /usr/src/haproxy-${version}
cd /usr/src/haproxy-${version} && make clean && \
make -j $(nproc) TARGET=linux-glibc USE_OPENSSL=1 USE_PCRE=1 USE_SYSTEMD=1 && \
make install PREFIX=/usr/local/haproxy && \
yum -y remove make gcc gcc-c++ && \
rm -rf /usr/src/haproxy-*
[root@localhost files]# cat haproxy.cfg
#--------------全局配置----------------
global
    log 127.0.0.1 local0  info
    #log loghost local0 info
    maxconn 20480
#chroot /usr/local/haproxy
    pidfile /var/run/haproxy.pid
    #maxconn 4000
    user haproxy
    group haproxy
    daemon
#---------------------------------------------------------------------
#common defaults that all the 'listen' and 'backend' sections will
#use if not designated in their block
#---------------------------------------------------------------------
defaults
    mode http
    log global
    option dontlognull
    option httpclose
    option httplog
    #option forwardfor
    option redispatch
    balance roundrobin
    timeout connect 10s
    timeout client 10s
    timeout server 10s
    timeout check 10s
    maxconn 60000
    retries 3
#--------------統計頁面配置------------------
listen admin_stats
    bind 0.0.0.0:8189
    stats enable
    mode http
    log global
    stats uri /haproxy_stats
    stats realm Haproxy\ Statistics
    stats auth admin:admin
    #stats hide-version
    stats admin if TRUE
    stats refresh 30s
#---------------web設置-----------------------
listen webcluster
    bind 0.0.0.0:80
    mode http
    #option httpchk GET /index.html
    log global
    maxconn 3000
    balance roundrobin
    cookie SESSION_COOKIE insert indirect nocache
    server web01 172.17.0.3:80 check inter 2000 fall 5
    server web02 172.17.0.4:80 check inter 2000 fall 5
[root@localhost files]#

2. 構建鏡像

[root@localhost ~]# docker build -t pengyudong/haproxy:v1.0 haproxy/
root@localhost ~]# docker images
pengyudong/haproxy   v1.0      8819e319cf32   19 minutes ago   418MB
[root@localhost ~]#

3. 創建容器

[root@localhost ~]# docker run -itd --name haproxy -p 8080:80 haproxy:v1.0
[root@localhost ~]# docker exec -it haproxy /bin/bash
[root@ce02ae7f027e haproxy]# ss -antl
State       Recv-Q      Send-Q           Local Address:Port            Peer Address:Port      Process
LISTEN      0           128                    0.0.0.0:80                   0.0.0.0:*
LISTEN      0           128                    0.0.0.0:8189                 0.0.0.0:*
[root@ce02ae7f027e haproxy]#
[root@localhost ~]# docker run -itd --name httpd pengyudong/httpd
462bd9babdcdac7f2abbb6da551858466659602bb3031129bb5b5de6e71853eb
[root@localhost ~]#  docker run -itd --name nginx nginx
0dffef28f17692db84e93c7caece9fbfe303d66b042bc1f40f13e0304c09227f
[root@localhost ~]# docker ps
CONTAINER ID   IMAGE                     COMMAND                  CREATED          STATUS          PORTS                                             NAMES
0dffef28f176   nginx                     "/docker-entrypoint.…"   8 minutes ago    Up 8 minutes    80/tcp                                            nginx
462bd9babdcd   pengyudong/httpd          "/usr/local/apache/b…"   8 minutes ago    Up 8 minutes    80/tcp                                            httpd
ce02ae7f027e   pengyudong/haproxy:v1.0   "/usr/bin/start.sh"      22 minutes ago   Up 22 minutes   8189/tcp, 0.0.0.0:8080->80/tcp, :::8080->80/tcp   haproxy
[root@localhost ~]#

到此這篇關于dockerfile構建haproxy的詳細過程(構建HAProxy的鏡像)的文章就介紹到這了,更多相關dockerfile構建haproxy內容請搜索腳本之家以前的文章或繼續瀏覽下面的相關文章希望大家以后多多支持腳本之家！
