Python+PyQt5+MySQL實現天氣管理系統
在本篇博客中,我利用Python語言其編寫界面庫PyQt5,然后通過連接MySQL數據庫,實現了一個簡單的天氣管理小系統,該系統包含簡單的增刪查改四個主要功能。本文旨在解析實現的程序,能夠讓讀者快速了解PyQt5圖形界面庫,然后可以初步實現這樣一個小的系統程序。
PyQt5簡介
PyQt5本身來自C++的界面庫Qt,經過一系列的封裝移植到Python里面,作為Python的一個圖像界面庫,它繼承了Python語言簡單易實現的特點,可以實現基本的界面效果。里面有許多類實現了我們想要的窗體、表格、文本、圖像等功能。在這個項目中也有所涉及,博主也是初次學這個庫,然后寫了這個小項目,里面可能會有一些不合適的地方,望諒解。
天氣系統數據庫
我將天氣系統數據存入MySQL數據庫中,提取數據時用Python的pymysql庫連接MySQL數據庫,對數據庫進行一系列操作。
這個數據庫主要包含城市、時間、各個空氣物質的含量、pm2.5、AQI指標等。如果需要數據可以在下面留言,我可以發給你們。
實現步驟
- 導入所需要用的Python包:PyQt5,pymysql……沒有的可以直接用pip安裝
- 創建所要編寫的界面類,初始化界面
- 連接數據庫,獲取數據
- 建立表格、按鈕布局
- 實現功能函數
- 測試
具體實現過程
#導入包 import pymysql from functools import partial from PyQt5.Qt import QWidget from PyQt5 import QtGui,QtWidgets from PyQt5.QtCore import Qt from PyQt5.QtWidgets import (QFrame,QApplication,QDialog, QDialogButtonBox, QMessageBox,QVBoxLayout, QLineEdit,QTableWidgetItem,QTableWidget,QHBoxLayout) #建立界面類 class creat_view(QDialog): def __init__(self,parent = None): super(creat_view,self).__init__(parent) #設置界面大小、名稱、背景 self.resize(1000,800) self.setWindowTitle('Database') self.setStyleSheet("background-image:url(tubiao_meitu.jpg)") #窗體屬性 self.setWindowFlags(Qt.Widget) #連接數據庫 db = pymysql.connect("localhost", "root", "password", "mysql",charset='utf8') #獲取游標、數據 cur = db.cursor() cur.execute("SELECT * FROM pm_25") data = cur.fetchall() #數據列名 col_lst = [tup[0] for tup in cur.description] #數據的大小 row = len(data) vol = len(data[0]) #插入表格 self.MyTable = QTableWidget(row,vol) font = QtGui.QFont('微軟雅黑',10) #設置字體、表頭 self.MyTable.horizontalHeader().setFont(font) self.MyTable.setHorizontalHeaderLabels(col_lst) #設置豎直方向表頭不可見 self.MyTable.verticalHeader().setVisible(False) self.MyTable.setFrameShape(QFrame.NoFrame) #設置表格顏色 self.MyTable.horizontalHeader().setStyleSheet('QHeaderView::section{background:skyblue}') #構建表格插入數據 for i in range(row): for j in range(vol): temp_data = data[i][j] # 臨時記錄,不能直接插入表格 data1 = QTableWidgetItem(str(temp_data)) # 轉換后可插入表格 self.MyTable.setItem(i, j, data1) #編輯按鈕 self.qle = QLineEdit() buttonBox = QDialogButtonBox() #增刪查改四個按鈕 addButton = buttonBox.addButton("&ADD",QDialogButtonBox.ActionRole) okButton = buttonBox.addButton("&OK",QDialogButtonBox.ActionRole) deleteButton = buttonBox.addButton("&DELETE",QDialogButtonBox.ActionRole) inquireButton = buttonBox.addButton("&QUERY",QDialogButtonBox.ActionRole) #設置按鈕內字體樣式 addButton.setFont(font) okButton.setFont(font) deleteButton.setFont(font) inquireButton.setFont(font) #垂直布局 layout = QVBoxLayout() layout.addWidget(self.qle) layout.addWidget(buttonBox) layout.addWidget(self.MyTable) self.setLayout(layout) addButton.clicked.connect(partial(self.add_data,cur,db))#插入實現 okButton.clicked.connect(partial(self.up_data, cur, db,col_lst))#插入實現 deleteButton.clicked.connect(partial(self.del_data,cur,db))#刪除實現 inquireButton.clicked.connect(partial(self.inq_data,db))#查詢實現 #添加空表格 def add_data(self,cur,db): #獲取行數 row = self.MyTable.rowCount() #在末尾插入一空行 self.MyTable.insertRow(row) #插入數據 def up_data(self,cur,db,col_lst): row_1 = self.MyTable.rowCount() value_lst = [] for i in range(len(col_lst)): if(len(self.MyTable.item(row_1-1,i).text())==0): value_lst.append(None) else: value_lst.append(self.MyTable.item(row_1-1,i).text()) tup_va_lst = [] for cl,va in zip(col_lst,value_lst): tup_va_lst.append((cl,va)) #插入語句 cur.execute( "INSERT INTO pm_25 VALUES (%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s,%s)",value_lst) #刪除 def del_data(self,cur,db): #是否刪除的對話框 reply = QMessageBox.question(self, 'Message', 'Are you sure to delete it ?', QMessageBox.Yes | QMessageBox.No, QMessageBox.No) if reply == QMessageBox.Yes: #當前行 row_2 = self.MyTable.currentRow() del_d = self.MyTable.item(row_2, 0).text() #在數據庫刪除數據 cur.execute("DELETE FROM pm_25 WHERE f_id = '"+del_d+"'") db.commit() #刪除表格 self.MyTable.removeRow(row_2) #查詢 def inq_data(self,db): txt = self.qle.text() #模糊查詢 if len(txt) != 0: cur.execute("SELECT * FROM pm25_fn WHERE f_area LIKE '%"+txt+"%' or f_place LIKE '%"+txt+"%'")# CONCAT('f_id','f_area','f_place','f_AQI','f_AQItype','f_PM25per1h'),concat(concat('%','#txt'),'%') data_x = cur.fetchall() self.MyTable.clearContents() row_4 = len(data_x) vol_1 = len(cur.description) #查詢到的更新帶表格當中 for i_x in range(row_4): for j_y in range(vol_1): temp_data_1 = data_x[i_x][j_y] # 臨時記錄,不能直接插入表格 data_1 = QTableWidgetItem(str(temp_data_1)) # 轉換后可插入表格 self.MyTable.setItem(i_x, j_y, data_1) #空輸入返回原先數據表格 else: self.MyTable.clearContents() cur.execute("SELECT * FROM pm_25") data_y = cur.fetchall() row_5 = len(data_y) vol_1 = len(cur.description) for i_x_1 in range(row_5): for j_y_1 in range(vol_1): temp_data_2 = data_y[i_x_1][j_y_1] # 臨時記錄,不能直接插入表格 data_2 = QTableWidgetItem(str(temp_data_2)) # 轉換后可插入表格 self.MyTable.setItem(i_x_1, j_y_1, data_2) def main(): #顯示 app = QApplication(sys.argv) c = creat_view() c.show() sys.exit(app.exec_()) main()
界面展示
大致就這么多啦,只要掌握PyQt的基本使用方法和數據庫的基本語法,做起來還是比較得心應手的。
更多學習資料請關注專題《管理系統開發》。
以上就是本文的全部內容,希望對大家的學習有所幫助,也希望大家多多支持腳本之家。
