using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Windows.Forms;
using System.Runtime.InteropServices;
using LmcLib;
namespace Ezcad_Funtion_Show
{
    public partial class Form1 : Form
    {
        public Form1()
        {
            InitializeComponent();
        }
        private void button1_Click(object sender, EventArgs e)
        {
            OpenFileDialog dlg = new OpenFileDialog();
            dlg.InitialDirectory = Environment.GetFolderPath(Environment.SpecialFolder.MyDocuments);
            dlg.Filter = "Ezd files (*.ezd)|*.ezd";
            if (dlg.ShowDialog() == DialogResult.OK)
            {
                textBox1.Text = dlg.FileName;
            }
        }
        public void ShowPreviewBmp()
        {
            int w = pictureBox1.Size.Width;
            int h = pictureBox1.Size.Height;
            if (w > h)
            {
                w = h;
            }
            else
            {
                h = w;
            }
            pictureBox1.Image = MarkEzdDll.GetCurPreviewImage(w, h);
        }
        private void Form1_Load(object sender, EventArgs e)
        {
            try
            {
                String dir = Application.StartupPath;
                int nErr = MarkEzdDll.Initialize(dir, false);
                MessageBox.Show("Initial=" nErr.ToString());
            }
            catch (Exception ex)
            {
                MessageBox.Show(ex.Message);
                this.Close();
            }
        }
        private void button2_Click(object sender, EventArgs e)
        {
            if (!backgroundWorker1.IsBusy)
            {
                backgroundWorker1.RunWorkerAsync();
            }
        }
        private void backgroundWorker1_DoWork(object sender, DoWorkEventArgs e)
        {
            int nErr = MarkEzdDll.Mark(false);
            //MessageBox.Show("Mark="   nErr.ToString());
        }
        private void backgroundWorker1_RunWorkerCompleted(object sender, RunWorkerCompletedEventArgs e)
        {
            //MessageBox.Show("Finish");
            //button8_Click(sender, e);
            ShowPreviewBmp();
        }
        private void Form1_FormClosed(object sender, FormClosedEventArgs e)
        {
            MarkEzdDll.Close();
        }
        private void button4_Click(object sender, EventArgs e)
        {
            MarkEzdDll.SetDevCfg();
        }
        private void button3_Click(object sender, EventArgs e)
        {
          MarkEzdDll.ChangeTextByName(textBox2.Text, textBox3.Text);
        }
        private void button6_Click(object sender, EventArgs e)
        {
            MarkEzdDll.ClearLibAllEntity();
            ShowPreviewBmp();
        }
        private void button5_Click(object sender, EventArgs e)
        {
            /// <summary>
            /// 向數據庫添加一條曲線對象
            /// 注意PtBuf必須為2維數組,且第一維為2,如 double[5,2],double[n,2],
            /// ptNum為PtBuf數組的第2維,如PtBuf為double[5,2]數組,則ptNum=5
            /// </summary>
            ///
            double[,] PtBuf = { { 0,0 }, { 10,0 }, { 10,10 }, { 0,10}, { 0,0 } };//10x10的矩形
            MarkEzdDll.AddCurveToLib(PtBuf, 5, "Curve", 0, 0);
            ShowPreviewBmp();
        }
        private void button7_Click(object sender, EventArgs e)
        {
            OpenFileDialog dlg = new OpenFileDialog();
            dlg.InitialDirectory = Environment.GetFolderPath(Environment.SpecialFolder.MyDocuments);
            dlg.Filter = "Ezd files (*.ezd)|*.ezd";
            if (dlg.ShowDialog() == DialogResult.OK)
            {
                textBox4.Text = dlg.FileName;
            }
        }
        bool test = false;
        private void button8_Click(object sender, EventArgs e)
        {
            if (test)
            {
                if (MarkEzdDll.LoadEzdFile(textBox1.Text) != 0)
                {
                    MessageBox.Show("打開Ezd文件"   textBox1.Text   "失敗!");
                }
                else
                {
                    test = false;
                }
            }
            else
            {
                if (MarkEzdDll.LoadEzdFile(textBox4.Text) != 0)
                {
                    MessageBox.Show("打開Ezd文件"   textBox4.Text   "失敗!");
                }
                else
                {
                    test = true;
                }
            }
            ShowPreviewBmp();
        }
    }
    public class MarkEzdDll
    {
        /// <summary>
        /// 初始化函數庫
        /// PathName 是MarkEzd.dll所在的目錄
        /// </summary>
        [DllImport("MarkEzd", EntryPoint = "lmc1_Initial2", CharSet= CharSet.Unicode,CallingConvention = CallingConvention.StdCall)]
        public static extern int Initialize(string PathName,bool bTestMode);
        [DllImport("MarkEzd", EntryPoint = "lmc1_SetDevCfg", CharSet = CharSet.Unicode, CallingConvention = CallingConvention.StdCall)]
        public static extern int SetDevCfg();
        [DllImport("MarkEzd", EntryPoint = "lmc1_Close",CharSet= CharSet.Unicode, CallingConvention = CallingConvention.StdCall)]
        public static extern int Close();
        [DllImport("MarkEzd", EntryPoint = "lmc1_LoadEzdFile", CharSet= CharSet.Unicode,CallingConvention = CallingConvention.StdCall)]
        public static extern int LoadEzdFile(string FileName);
        [DllImport("MarkEzd", EntryPoint = "lmc1_Mark",CharSet= CharSet.Unicode, CallingConvention = CallingConvention.StdCall)]
        public static extern int Mark(bool Fly);
       [DllImport("MarkEzd", EntryPoint = "lmc1_ChangeTextByName", CharSet = CharSet.Unicode, CallingConvention = CallingConvention.StdCall)]
        public static extern int ChangeTextByName(string EntName, string NewText);
        [DllImport("gdi32.dll")]
        internal static extern bool DeleteObject(IntPtr hObject);
        [DllImport("MarkEzd", EntryPoint = "lmc1_GetPrevBitmap2", CharSet = CharSet.Unicode, CallingConvention = CallingConvention.StdCall)]
        internal static extern IntPtr GetCurPrevBitmap(int bmpwidth, int bmpheight);
        public static Image GetCurPreviewImage(int bmpwidth, int bmpheight)
        {
            IntPtr pBmp = GetCurPrevBitmap(bmpwidth, bmpheight);
            Image img = Image.FromHbitmap(pBmp);
            MarkEzdDll.DeleteObject(pBmp);
            return img;
        }
        [DllImport("MarkEzd", EntryPoint = "lmc1_AddCurveToLib", CharSet = CharSet.Unicode, CallingConvention = CallingConvention.StdCall)]
        public static extern int AddCurveToLib([MarshalAs(UnmanagedType.LPArray)] double[,] PtBuf, int ptNum, string strEntName, int nPenNo, int bHatch);
        [DllImport("MarkEzd", EntryPoint = "lmc1_ClearEntLib", CharSet = CharSet.Unicode, CallingConvention = CallingConvention.StdCall)]
        public static extern int ClearLibAllEntity();
    }
}
