import tkinter as tk
from tkinter import ttk, messagebox, filedialog
import threading
import ipaddress
import socket
import queue
import time
import xml.etree.ElementTree as ET
from datetime import datetime
import os
import matplotlib.pyplot as plt
from matplotlib.figure import Figure
from matplotlib.backends.backend_tkagg import FigureCanvasTkAgg
import matplotlib
matplotlib.use('TkAgg')

class DatabaseScanner:
    def __init__(self):
        self.root = tk.Tk()
        self.root.title("數據庫服務器掃描工具")

        # 獲取屏幕尺寸
        screen_width = self.root.winfo_screenwidth()
        screen_height = self.root.winfo_screenheight()

        # 設置窗口初始大小為屏幕的80%寬度和90%高度
        window_width = int(screen_width * 0.8)
        window_height = int(screen_height * 0.9)  # 增加高度比例

        # 計算窗口位置使其居中
        x = (screen_width - window_width) // 2
        y = (screen_height - window_height) // 2

        # 設置窗口大小和位置
        self.root.geometry(f"{window_width}x{window_height}+{x}+{y}")

        # 設置窗口最小尺寸
        self.root.minsize(800, 800)  # 增加最小高度

        # 設置主題色
        self.colors = {
            'bg': '#f0f0f0',
            'frame_bg': '#ffffff',
            'button': '#2196f3',
            'button_hover': '#1976d2',
            'success': '#4caf50',
            'warning': '#ff9800',
            'error': '#f44336'
        }

        # 設置樣式
        self.style = ttk.Style()
        self.style.configure('Main.TLabelframe', background=self.colors['frame_bg'])
        self.style.configure('Main.TLabelframe.Label', background=self.colors['frame_bg'],
                           font=('微軟雅黑', 10, 'bold'))
        self.style.configure('Scan.TButton', background=self.colors['button'],
                           font=('微軟雅黑', 9))
        self.style.configure('Report.TButton', background=self.colors['success'],
                           font=('微軟雅黑', 9))

        # 創建數據存儲變量
        self.scan_running = False
        self.result_queue = queue.Queue()
        self.db_results = {
            'Oracle': [],
            'SQL Server': [],
            'MySQL': [],
            'PostgreSQL': [],
            'SQLite': []
        }

        self.root.configure(bg=self.colors['bg'])
        self.setup_ui()

    def setup_ui(self):
        # 創建主框架，使用grid布局
        main_frame = ttk.Frame(self.root)
        main_frame.grid(row=0, column=0, sticky="nsew")

        # 配置root和main_frame的grid權重
        self.root.grid_rowconfigure(0, weight=1)
        self.root.grid_columnconfigure(0, weight=1)

        # 調整各區域的相對大小比例
        main_frame.grid_rowconfigure(0, weight=0)  # 掃描設置固定高度
        main_frame.grid_rowconfigure(1, weight=1)  # 進度日志區域
        main_frame.grid_rowconfigure(2, weight=3)  # 增加圖表區域的比例
        main_frame.grid_rowconfigure(3, weight=4)  # 增加結果區域的比例
        main_frame.grid_columnconfigure(0, weight=1)

        # 輸入框框架
        input_frame = ttk.LabelFrame(main_frame, text="掃描設置", padding=10, style='Main.TLabelframe')
        input_frame.grid(row=0, column=0, sticky="ew", padx=10, pady=5)

        ttk.Label(input_frame, text="IP地址/網段:", background=self.colors['frame_bg'],
                 font=('微軟雅黑', 9)).grid(row=0, column=0, padx=5)
        self.ip_entry = ttk.Entry(input_frame, width=40, font=('微軟雅黑', 9))
        self.ip_entry.grid(row=0, column=1, padx=5)
        self.ip_entry.insert(0, "192.168.1.0/24")

        button_frame = ttk.Frame(input_frame, style='Main.TLabelframe')
        button_frame.grid(row=0, column=2, padx=5)

        self.scan_button = ttk.Button(button_frame, text="開始掃描",
                                    command=self.start_scan, style='Scan.TButton')
        self.scan_button.pack(side=tk.LEFT, padx=2)

        self.report_button = ttk.Button(button_frame, text="生成報告",
                                      command=self.generate_report, style='Report.TButton')
        self.report_button.pack(side=tk.LEFT, padx=2)

        # 配置input_frame的列權重
        input_frame.columnconfigure(1, weight=1)

        # 進度日志框架
        log_frame = ttk.LabelFrame(main_frame, text="掃描進度", padding=10, style='Main.TLabelframe')
        log_frame.grid(row=1, column=0, sticky="ew", padx=10, pady=5)

        self.progress_var = tk.StringVar(value="等待開始掃描...")
        self.progress_label = ttk.Label(log_frame, textvariable=self.progress_var,
                                      background=self.colors['frame_bg'],
                                      font=('微軟雅黑', 9))
        self.progress_label.pack(fill=tk.X)

        self.log_text = tk.Text(log_frame, height=4, font=('微軟雅黑', 9))
        self.log_text.pack(fill=tk.BOTH, expand=True)
        self.log_text.configure(bg='#fafafa', fg='#333333')
        log_scrollbar = ttk.Scrollbar(log_frame, command=self.log_text.yview)
        log_scrollbar.pack(side=tk.RIGHT, fill=tk.Y)
        self.log_text.config(yscrollcommand=log_scrollbar.set)

        # 添加統計圖表框架
        chart_frame = ttk.LabelFrame(main_frame, text="數據庫統計", padding=10, style='Main.TLabelframe')
        chart_frame.grid(row=2, column=0, sticky="nsew", padx=10, pady=5)

        # 創建圖表
        self.figure = Figure(dpi=100)  # 移除固定figsize
        self.figure.patch.set_facecolor(self.colors['frame_bg'])
        self.chart_ax = self.figure.add_subplot(111)
        self.canvas = FigureCanvasTkAgg(self.figure, master=chart_frame)
        self.canvas.get_tk_widget().pack(fill=tk.BOTH, expand=True)

        # 初始化圖表
        self.update_chart()

        # 結果顯示框架
        result_frame = ttk.LabelFrame(main_frame, text="掃描結果", padding=10, style='Main.TLabelframe')
        result_frame.grid(row=3, column=0, sticky="nsew", padx=10, pady=5)

        # 創建數據庫類型標簽頁
        self.notebook = ttk.Notebook(result_frame)
        self.notebook.pack(fill=tk.BOTH, expand=True)

        # 為不同數據庫類型設置不同的顏色
        db_colors = {
            'Oracle': '#f44336',
            'SQL Server': '#2196f3',
            'MySQL': '#4caf50',
            'PostgreSQL': '#ff9800',
            'SQLite': '#9c27b0'
        }

        self.db_text_widgets = {}
        for db_type in self.db_results.keys():
            frame = ttk.Frame(self.notebook, style='Main.TLabelframe')
            self.notebook.add(frame, text=f"{db_type} (0)")

            text_widget = tk.Text(frame, height=8, font=('微軟雅黑', 9))
            text_widget.pack(fill=tk.BOTH, expand=True)
            text_widget.configure(bg='#fafafa', fg=db_colors[db_type])
            scrollbar = ttk.Scrollbar(frame, command=text_widget.yview)
            scrollbar.pack(side=tk.RIGHT, fill=tk.Y)
            text_widget.config(yscrollcommand=scrollbar.set)

            self.db_text_widgets[db_type] = text_widget

        # 綁定窗口大小改變事件
        self.root.bind('<Configure>', self.on_window_resize)

    def on_window_resize(self, event):
        """當窗口大小改變時調整圖表大小"""
        if hasattr(self, 'canvas'):
            # 延遲更新以避免頻繁刷新
            self.root.after_cancel(self._resize_job) if hasattr(self, '_resize_job') else None
            self._resize_job = self.root.after(100, self.update_chart)

    def validate_ip_input(self, ip_input):
        try:
            if '/' in ip_input:  # CIDR格式
                ipaddress.ip_network(ip_input, strict=False)
            else:  # 單個IP地址
                ipaddress.ip_address(ip_input)
            return True
        except ValueError:
            return False

    def start_scan(self):
        if self.scan_running:
            self.scan_running = False
            self.scan_button.config(text="開始掃描")
            return

        ip_input = self.ip_entry.get().strip()
        if not self.validate_ip_input(ip_input):
            messagebox.showerror("錯誤", "請輸入有效的IP地址或網段")
            return

        # 清空之前的結果
        for db_type in self.db_results:
            self.db_results[db_type] = []
            self.db_text_widgets[db_type].delete(1.0, tk.END)
            self.notebook.tab(list(self.db_results.keys()).index(db_type), text=f"{db_type} (0)")

        # 重置圖表
        self.update_chart()

        self.scan_running = True
        self.scan_button.config(text="停止掃描")

        # 啟動掃描線程
        scan_thread = threading.Thread(target=self.scan_network, args=(ip_input,))
        scan_thread.daemon = True
        scan_thread.start()

        # 啟動更新UI的線程
        self.root.after(100, self.update_results)

    def scan_network(self, ip_input):
        try:
            if '/' in ip_input:  # 網段
                network = ipaddress.ip_network(ip_input, strict=False)
                ip_list = list(network.hosts())
            else:  # 單個IP
                ip_list = [ipaddress.ip_address(ip_input)]

            total_ips = len(ip_list)
            for index, ip in enumerate(ip_list, 1):
                if not self.scan_running:
                    break

                ip_str = str(ip)
                progress = f"正在掃描: {ip_str} ({index}/{total_ips})"
                self.result_queue.put(("progress", progress))
                self.result_queue.put(("log", f"正在掃描 {ip_str}...\n"))

                # 檢查各種數據庫端口
                self.check_database_ports(ip_str)

        except Exception as e:
            self.result_queue.put(("error", f"掃描出錯: {str(e)}"))

        finally:
            self.scan_running = False
            self.result_queue.put(("progress", "掃描完成"))
            self.result_queue.put(("log", "掃描已完成\n"))
            self.root.after(0, lambda: self.scan_button.config(text="開始掃描"))

    def check_database_ports(self, ip):
        # 定義數據庫默認端口
        db_ports = {
            'Oracle': [1521],
            'SQL Server': [1433],
            'MySQL': [3306],
            'PostgreSQL': [5432],
            'SQLite': []  # SQLite是文件型數據庫，沒有網絡端口
        }

        for db_type, ports in db_ports.items():
            for port in ports:
                try:
                    sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
                    sock.settimeout(1)
                    result = sock.connect_ex((ip, port))
                    if result == 0:
                        self.result_queue.put(("found", db_type, ip, port))
                    sock.close()
                except:
                    continue

    def update_chart(self):
        """更新統計圖表"""
        self.chart_ax.clear()

        # 獲取圖表區域的大小
        chart_width = self.canvas.get_tk_widget().winfo_width()
        chart_height = self.canvas.get_tk_widget().winfo_height()

        # 調整圖表的縱橫比
        aspect_ratio = chart_height / chart_width

        # 根據窗口大小調整圖表尺寸，保持合適的縱橫比
        self.figure.set_size_inches(chart_width/100, (chart_width * aspect_ratio)/100)

        # 準備數據
        db_types = list(self.db_results.keys())
        counts = [len(ips) for ips in self.db_results.values()]
        colors = ['#f44336', '#2196f3', '#4caf50', '#ff9800', '#9c27b0']

        # 創建柱狀圖
        bars = self.chart_ax.bar(db_types, counts, color=colors)

        # 設置圖表樣式
        plt.rcParams['font.sans-serif'] = ['Microsoft YaHei']  # 使用微軟雅黑字體
        plt.rcParams['axes.unicode_minus'] = False

        self.chart_ax.set_ylabel('數量', fontsize=10)
        self.chart_ax.set_title('數據庫服務器統計', fontsize=12, pad=10)

        # 設置Y軸范圍和刻度
        max_count = max(counts) if counts else 0
        self.chart_ax.set_ylim(0, max_count + 1 if max_count > 0 else 1)
        self.chart_ax.yaxis.set_ticks(range(0, int(max_count + 2)))

        # 設置背景顏色和網格
        self.figure.patch.set_facecolor(self.colors['frame_bg'])
        self.chart_ax.set_facecolor('#f8f9fa')
        self.chart_ax.grid(True, axis='y', linestyle='--', alpha=0.3)

        # 美化X軸標簽
        self.chart_ax.set_xticklabels(db_types, rotation=0, fontsize=9)

        # 在柱子上顯示具體數值
        for bar in bars:
            height = bar.get_height()
            self.chart_ax.text(bar.get_x() + bar.get_width()/2., height,
                             f'{int(height)}',
                             ha='center', va='bottom',
                             fontsize=10,
                             fontweight='bold')

        # 調整布局，確保所有元素都能顯示
        self.figure.tight_layout()

        # 刷新畫布
        self.canvas.draw()

    def update_results(self):
        while not self.result_queue.empty():
            message = self.result_queue.get()
            if message[0] == "found":
                _, db_type, ip, port = message
                if ip not in self.db_results[db_type]:
                    self.db_results[db_type].append(ip)
                    self.db_text_widgets[db_type].insert(tk.END, f"{ip}:{port}\n")
                    self.notebook.tab(list(self.db_results.keys()).index(db_type),
                                   text=f"{db_type} ({len(self.db_results[db_type])})")
                    self.result_queue.put(("log", f"發現 {db_type} 服務器: {ip}:{port}\n"))
                    # 更新統計圖表
                    self.update_chart()
            elif message[0] == "error":
                messagebox.showerror("錯誤", message[1])
            elif message[0] == "progress":
                self.progress_var.set(message[1])
            elif message[0] == "log":
                self.log_text.insert(tk.END, message[1])
                self.log_text.see(tk.END)

        if self.scan_running:
            self.root.after(100, self.update_results)

    def generate_report(self):
        if not any(self.db_results.values()):
            messagebox.showwarning("警告", "沒有掃描結果可供生成報告！")
            return

        try:
            # 創建XML報告
            root = ET.Element("ScanReport")
            ET.SubElement(root, "ScanTime").text = datetime.now().strftime("%Y-%m-%d %H:%M:%S")
            ET.SubElement(root, "ScanTarget").text = self.ip_entry.get()

            databases = ET.SubElement(root, "Databases")
            for db_type, ips in self.db_results.items():
                db_elem = ET.SubElement(databases, "Database")
                ET.SubElement(db_elem, "Type").text = db_type
                ET.SubElement(db_elem, "Count").text = str(len(ips))
                servers = ET.SubElement(db_elem, "Servers")
                for ip in ips:
                    server = ET.SubElement(servers, "Server")
                    server.text = ip

            # 保存文件對話框
            file_path = filedialog.asksaveasfilename(
                defaultextension=".xml",
                filetypes=[("XML files", "*.xml")],
                initialfile=f"scan_report_{datetime.now().strftime('%Y%m%d_%H%M%S')}.xml"
            )

            if file_path:
                tree = ET.ElementTree(root)
                tree.write(file_path, encoding="utf-8", xml_declaration=True)
                self.result_queue.put(("log", f"掃描報告已保存至: {file_path}\n"))
                messagebox.showinfo("成功", "掃描報告已生成！")

        except Exception as e:
            messagebox.showerror("錯誤", f"生成報告時出錯: {str(e)}")

    def run(self):
        self.root.mainloop()

if __name__ == "__main__":
    scanner = DatabaseScanner()
    scanner.run()
